13.3" Bezel free PCAP On-wall mount PC

touchscreen pc on wall mount 13.3 inch front
13.3" Bezel free PCAP On-wall mount PC
Net price (excl.VAT) €850,00
Art.No.:
1020153212
Brand:
A1Touch Solution
Type: BFR133-GPCAP-M3A-WMB; 13.3" On wall mount FULL HD projected capacitive touchscreen monitorwith integrated computer type M3A, Intel J4125 quad core tot 2.7 Ghz, 6Gb ram, Flash 128 Gb eMMC with Win10 PRONL installed. (1x internet and 1x usb port external available).
Descriptions: 13.3 inch on wall monitor pcap touchpc, bezel free with 3mm thick full glass and black coated metal case for vandal proof 24/7 use in public spaces.
Unit is in stock

Product Features:

- Win10 Pro multipurpose system.
- Bezel free design with glass surface.
- Precise multi-point (10 points) touching.
- Maintenance free.
- Complete metal monitor with strong stability.
- Auto on after power failure.
- Unit can be touched with finger, hand gloves or stylus pencil.
- Fast touch response (less than 10 ms).


Specifications:

General

Model:
BFR133-M3A-WMB
Size:
13.3"
Panel Type:
IPS
Backlight:
LED
Display colour:
262K
Color:
Black
Material:
Metal housing, Glass cover glass
Mounting Option:
VESA 75x75 and 100x100 mm
Video Inputs
Inputs: VGA/ HDMI/ BNC/ Composite/ USB
Dimensions

Outside dimensions frame (wxhxd)
354*224*38 mm
Active area (wxh)
293.76*165.24 mm
Display

Native resolution:
1920*1080 @60HZ
Ratio:
16:9
Contrast:
800:1
Brightness:
350 cd/m
Viewing Angle (H/V):
178/178
Backlight life:
Min.15.0000 hrs
Control:
OSD Control

Processor



Type:

Intel® Celeron® Processor J4125

Platform:

Intel Gemini lake Platform J4125

Performance:

4-core, 4-threads, 4MB Cache, up to 2.7 GHz

GPU:

Intel® UHD Graphics 600,

DirectX 12.0, OpenGL 4.3, OpenCL 2.0

Memory / Storage



Ram:

6GB Ram DDR4 -2400Mhz

Storage:

128GB (Emmc) storage with Windows10Pro installed

Ports



USB:

1x USB3.0 external available,

Ethernet:

1x ethernet RJ45, 1Gb external available.

Power:

1x button  (only on request)  Normally unit starts when power on.

Touchscreen

Touch Technology:
Projected capacitive Touch (G+G)
Detected touches
10 touches.
Response time:
<10ms
Input Method:
Finger, hand gloves, or conductive stylus
Touch times:
Unlimited
Touch Activation Force:
No minimum touch activation force is required.
Controller type:
EETI chipset 31xx
Operating System Support:
Windows2000, XP, 7, 8, 10, 11, Android, MAC and Linux.
Environment

Temperature:
Operating: 0°C ~ 50°C Storage: -20°C ~ 60°C
Relative Humidity:
Operating: 90%(non-condensing at max 40°C)
Storage: 90%(non-condensing at max 40°C)
Altitude:
Up to 3000m
Electrical

Scan frequency:
60Hz
Operation Voltage:
Typical +DC 12V, +/- 10% (24 volt option).
Power Supply:
110-220V AC to 12Volt DC, min. 3.5A
Power:
15 W
Packing

Agency Approvals:
CE, FCC, RoHS
Weight net.:
3.5 kg

Options:


Standard delivery: Our touchscreen system standard includes: pcap touchscreen with integrated computer and windows10 plug and play installed + 220 – 12 Volt Power Supply.
Cooling:
- With active cooling (standard) :   the silent cooler is ideal for rooms without ventilation to achieve optimal cooling of processor
- With passive cooling : Use this option if you have dirty air or need absolute no noise (room should be ventilated to provide processor with cool air stream).

Storage capacity mSata:
- Diskless (standard)   (unit has 32Gb storage and no extra storage is needed).
- Options:  60 - 120 - 250 - 500 Gb extra mSata SSD can be chosen for extra storage capacity

Input equipment:
- None (standard)  (if you do not need extra keyboard/ mouse but only use touchscreen.
Wireless keyboard + mouse.
Wireless keyboard with integrated mousepad.

Vesa wall mount bracket:
- Without wall mount bracket (standard);  if you have your own bracket or mounting method
- With wall mount bracket

Accessories:
- No accessories (standard)
- With stylus pen and holder:


Specifications touchmonitor:

Specs 13.3 inch desktop touch Monitor manual
General Specs including integrated M3A computer: Specs M1A integrated computer
Driver downloads : Touchscreen driver downloads
